宽带PON网络单线双接入设备

产品特点：

易安装、隐蔽性强：单线双接入是无源设备，故障率低；体积小巧，可以在各种

复杂的环境中快速安装，隐蔽性强。

插损小：单线双接入设备成对插损＜1.6dB，上线后线路裕量范围内。

现在查询下载

类别

热门产品

产品详细信息

宽带PON网络单线双接入设备

单线双接入-适用场景

单芯皮线入户的国标(强标)小区，一房单用户多条宽带、一房多租户多条宽带、一房宽带未到期快速并网/转网的场景，解决皮线二次入户困难的问题，利用现有入户线完成宽带快速装机。

产品图

ABS 插片盒子 ABS带尾纤模块

单线双接入- 同运营商开通两条宽带场景

利用一芯入户光缆，为商务楼宇企业客户、一房多租户，同时开通两个宽带业务。

单线双接入-单用户开通两条不同运营商宽带应用说明

如上图所示，国标小区很多为入户光纤暗管，重新拉线难度较大，且驻地网机房至用户家为光缆与皮线直熔，无法扩容，需要重新布放光缆和皮线，不确定性大，现场勘察后退单亦时有发生。

采用单线双接入后无论移动采用 EPON/GPON 还是 10GEPON （对称型）/XGPON 覆盖，均可以通过“单线双接入”释放 1491/1310 通道或者1577/1270 通道来进行移动和联通宽带的同时入户。从而满足一房单用户多宽带、一房多租户多宽带、一房宽带未到期快速并网/转网的需求。单线双接入设备具备盒式插片盒、模块盒式、钢管式三种形态， A-B 端任意组合均可对通，可满足楼道分纤箱、楼道竖井、光交箱托盘等场景的安装需要。

单线双接入-技术可行性

产品结构图

ABS 插片盒子

ABS 模块
