Features Support line rates from 103.125 Gb/s to 112.2 Gb/s OTU4 Built-in 4-channel Clock and Data Recovery (CDR) in TX and RX LAN WDM EML laser and PIN receiver with SOA Up to 80km reach for G.652 SMF Hot pluggable 38 pin electrical interface QSFP28 MSA compliant BIDI LC optical receptacle RoHS-10 compliant and lead-free Excellent EMI performance Single +3.3V power supply Maximum power consumption 5.5W Case operating temperature Commercial: 0 ~ 70℃ Extended: -5 ~ +85℃ Applications 100GBASE-ZR4 Ethernet Links Infiniband QDR and DDR interconnects Telecom networking

Features Up to 106.25Gbps data rate by PAM4 modulation 1x100G PAM4 EML laser Duplex LC receptacle optical interface Single +3.3V power supply DDM function implemented Hot-pluggable QSFP28 form factor Maximum link length of 500m on SMF fiber Low power dissipation:<3.5W International class 1 laser safety certified Operating temperature range: 0℃ ~ +70 ℃ Compliant with ROHS6.0 Applications 100GBASE Ethernet Links Switch & Router Connections Data Centers Standards IEEE 802.3bm IEEE 802.3cd 100G Lambda MSA QSFP MSA SFF-863

Feature Compliant with QSFP28 MSA Compliant with SWDM MSA Compliant with IEEE802.3bm CAUI-4 Hot-pluggable QSFP28 form factor 4x25Gb/s 850mm VCSEL-based transmitter Supports 103.1Gbps aggregate bit rate Power dissipation<3.5W Maximum link length of 150m on OM5 multi mode Fiber Case temperature range of 0℃ to 70℃ Duplex LC receptacles CAUI-4 electrical interface RoHS compliant Applications 100G Ethernet over Duplex MMF

Features Supports multi-rate (100GE and OTU4); from 103.1Gb/s to 111.8Gb/s aggregate; Lane bit rate 25.78 Gb/s 100GE, 27.95 Gb/s OTU4; Up to 40km transmission on SMF; LANWDM laser and PIN receiver with SOA; High speed I/O electrical interface (CAUI-4); MDIO interface with integrated Digital Diagnostic CFP2 MSA package with duplex LC connector; Single +3.3V power supply; Maximum power consumption 14W; Operating case temperature: 0 to +70 °C; Complies with IEEE802.3ba and ITU-T G.959.1; Complies with EU Directive 2015/863/EU;   Application 100GBASE-ER4;

Features Supports single-rate 103.1Gb/s aggregate(100GE); Lane bit rate 25.78 Gb/s 100GbE; Up to 10km transmission on SMF; LAN WDM laser and PIN receiver; High speed I/O electrical interface (CAUI-4); MDIO interface with integrated Digital Diagnostic monitoring; CFP2 MSA package with duplex LC connector; Single +3.3V power supply; Maximum power consumption 6W; Operating case temperature: -5 to +70 °C; Complies with IEEE802.3bm; Complies with EU Directive 2015/863/EU;   Application 100GBASE-LR4;

Features Supports multi-rate (100GE and OTU4); from 103.1Gb/s to 111.8Gb/s aggregate; Up to 10km transmission on SMF; LANWDM laser and PIN receiver with SOA; High speed I/O electrical interface (CAUI-4); MDIO interface with integrated Digital Diagnostic CFP2 MSA package with duplex LC connector; Single +3.3V power supply; Maximum power consumption 12W; Operating case temperature: 0 to +70 °C; Complies with IEEE802.3ba and ITU-T G.959.1; Complies with EU Directive 2015/863/EU; Application 100GBASE-LR4

Features Supports multi-rate (100GE and OTU4) from 103.1Gb/s to 111.8Gb/s aggregate. Lane bit rate 25.78 Gb/s 100GE, 27.95 Gb/s OTU4 Up to 10km transmission on SMF High speed I/O electrical interface (CAUI-10) MDIO interface with integrated Digital Diagnostic monitoring CFP MSA package with duplex LC connector Single +3.3V power supply Maximum power consumption 12W Operating case temperature: 0 to +70 °C Complies with IEEE802.3ba and ITU-T G.959.1 Complies with EU Directive 2015/863/EU Application 100GBASE-LR4

Features CAUI -10 Electrical Interface:10 Lanes @10Gbit/s for CFP port CAUI -4 Electrical Interface:4 Lanes @25.78Gbit/s for QSFP28 port Hot Pluggable Low latency FEC MDIO, I2C Support Compliant to CFP MSA Case operating temperature: 0 to 70 °C The RQ-CFP-QSFP28-F Adaptor Module converts a 100 Gigabit CFP port into a 100 Gigabit QSFP28 port. With the Adaptor Module, customers have the flexibility to use the 100 Gigabit CFP interface port of a switch with CFP modules or QSFP28 modules. For 100G Ethernet, reference clock can switch 161.133mhz or 644.531mhz; For OUT 4, reference clock can switch 174.703mhz or 698.812mhz; Users can control whether FEC function is enabled or not through register configuration.

Features Supports 100GBASE-LR1- 10 BIDI Lane signaling rate 106.25Gb/s with PAM4 Up to 10km transmission on SMF EML Laser and PIN receiver 4x25.78Gb/s with NRZ electrical interface (CAUI-4) High speed I/O electrical interface I2C interface with integrated Digital Diagnostic monitoring QSFP28 MSA package with simplex LC connector Single +3.3V power supply Support HW TX_DIS and RX_LOS for telecom application Maximum power consumption 4 W Operating case temperature: 0 to +70 °C Compliant to 802.3cu, SFF-8636&SFF-8679 standard Complies with EU Directive 2015/863/EU Application 100GBASE-LR1- 10 BIDI

Features Supports 100GBASE-ER1-40 BIDI Lane signaling rate 106.25Gb/s with PAM4 Up to 40km transmission on SMF EML laser and APD receiver 4x25.78Gb/s with NRZ electrical interface (CAUI-4) High speed I/O electrical interface I2C interface with integrated Digital Diagnostic monitoring QSFP28 MSA package with simplex LC connector Single +3.3V power supply Maximum power consumption 4.5 W Operating case temperature: 0 to +70 °C Compliant to 802.3cu, SFF-8636&SFF-8679 standard Complies with EU Directive 2015/863/EU Application 100GBASE-ER1-40 BIDI

Features Supports 100GBASE-LR1-20 BIDI Lane signaling rate 106.25Gb/s with PAM4 Up to 20km transmission on SMF EML Laser and PIN receiver 4x25.78Gb/s with NRZ electrical interface (CAUI-4) High speed I/O electrical interface I2C interface with integrated Digital Diagnostic monitoring QSFP28 MSA package with simplex LC connector Single +3.3V power supply Support HW TX_DIS and RX_LOS for telecom application Maximum power consumption 4.5 W Operating case temperature: 0 to +70 °C Compliant to 802.3cu, SFF-8636&SFF-8679 standard Complies with EU Directive 2015/863/EU Applications 100GBASE-LR1-20 BIDI

Features High density interconnectivity Supports 100Gb/s data rate links up to 2km on a Single mode Fiber (SMF) Industry standard QSFP28 form factor Power Dissipation < 3.5W Single 3.3V Power Supply Applications Data Center interconnections 100GBASE Ethernet links
