10G DWDM SFP+ Optical Transceiver

10G SFP+ optical transceiver module, support 10Gb/s and up to 100 km transmission, including: SFP+ SR, SFP+ LR, SFP+ ER, SFP+ ZR, etc.

It works in high-speed IDC connection solutions, 5G network front-haul solution, network switch, PTN, OTN and so on.

现在查询

类别

热门产品

产品详细信息

10G DWDM SFP+ Optical Transceiver

Features

Supports10Gb/s bit rate
Duplex LC Connector
Hot Pluggable SFP+ form factor
Digital diagnostic monitoring support

Single 3.3V power supply
RoHS-10 compliant and lead-free
All-metal housing for superior EMI performance
Case operating temperature:0℃ to+ 70℃/ -40℃ to +85℃

Order information

Product Number	Data Rate(Gb/s)	Wavelength(nm)	Reach(km)	LD	Tx Power(dBm)	PD	Rx Sens(dBm)	Temperature(℃)
RSPD-10GD40-XX/I	10	100GHZ /50GHZ DWDM	40	DFB	-1~3	PIN	<-15.8	0~70/-40~85
RSPD-10GD80-XX/I	10	100GHZ /50GHZ DWDM	80	DFB	-1~3	APD	<-23	0~70/-40~85
RSPD-10GS100-XX/I	10	100GHZ /50GHZ DWDM	100	EML	0~6	APD	<-26	0~70/-40~85
