25G SFP28 Optical Transceiver

25G SFP28 optical transceiver module, support 25Gb/s and SR up to 100 m transmission, LR 25G SFP28 up to 10 km transmission, and ER 25G SFP28 up to 40 km transmission, it works in high-speed IDC connection solutions, and so on.
  • 产品详细信息


25G SFP28 OpticalTransceiver



Features



  • Supports25Gb/s bit rate
  • Duplex LC Connector
  • Hot Pluggable SFP28 form factor
  • Digital diagnostic monitoring support
  • Single 3.3V power supply
  • RoHS-10 compliant and lead-free
  • All-metal housing for superior EMI performance
  • Case operating temperature:0℃ to+ 70℃/ -40℃ to +85℃


Order information


Product Number

Data Rate(Gb/s)

Wavelength(nm)

Reach(km)

LD

Tx Power(dBm)

PD

Rx Sens(dBm)

Temperature(℃)

RSPD-25G-SR

25

850

0.1

VCSEL

-5~2.4

PIN

<-10.3

0~70

RSPD-25G-LR

25

1310

10

DFB

-7.0~2.0

PIN

<-14

0~70

RSPD-25G-LR

25

1310

10

DFB

-7.0~2.0

PIN

<-14

-40~85

RSPD-25G-ER

25

1310

30

DFB

-3.0~6.0

APD

<-18

0~70

RSPD-25G-ER

25

1310

30

DFB

-3.0~6.0

APD

<-18

-40~85

RQ-25G-ER

25

1310

40

EML

-3.0~6.0

APD

<-21

0~70

RSPD-25G-ER

25

1310

40

EML

-3.0~6.0

APD

<-21

-40~85
