3G Video CWDM SFP Optical Transceiver support 1080P 60HZ Video

3G Video CWDM SFP optical transceiver module, support 1080p 60HZ video and up to 80 km transmission.

It works in optical video transmission.

现在查询

类别

热门产品

产品详细信息

3G Video CWDM SFP Optical Transceiver support 1080P 60HZ Video

Features

Supports 3.15Gb/s bit rate for 1080P 60HZ Video
Single TX and single RX over a single fiber, LC Connector
Hot Pluggable SFP form factor
Digital diagnostic monitoring support

Single 3.3V power supply
RoHS-10 compliant and lead-free
All-metal housing for superior EMI performance
Case operating temperature:0℃ to+ 70℃/ -40℃ to +85℃

Order Information

Product Number	Data Rate(Gb/s)	Wavelength(nm)	Reach(km)	LD	Tx Power(dBm)	PD	Rx Sens(dBm)	Temperature(℃)
RSPD-3GC20-XXT/I	3G	CWDM	20	FP	-9~-3	/	/	0~70/-40~85
RSPD-3GC20-XXR/I	3G	CWDM	20	/	/	PIN	<-18	0~70/-40~85
RSPD-3GC40-XXT/I	3G	CWDM	40	DFB	-2~3	/	/	0~70/-40~85
RSPD-3GC40-XXR/I	3G	CWDM	40	/	/	PIN	<-18	0~70/-40~85
RSPD-3GC80-XXT/I	3G	CWDM	80	DFB	0~5	/	/	0~70/-40~85
RSPD-3GC80-XXR/I	3G	CWDM	80	/	/	APD	<-28	0~70/-40~85
