400G QSFP28-DD FR4 CWDM4 2km LC Optical Transceiver

400G QSFP-DD FR4 optical transceiver module, support 400Gb/s and up to 2 km transmission on SM fiber, it works in high-speed IDC connection solutions.
  • 产品详细信息

400Gb/s QSFP28-DD FR4 CWDM4Optical Transceiver


Product Features


  • Supports 400Gb/s FR4
  • Lane bit rate 106.25Gb/s with PAM4
  • CWDM4 (1271/1291/1311/1331nm) EML laser and PIN receiver
  • Up to 2km transmission on SMF
  • 8x53.125Gb/s with PAM4 electrical interface(400GAUI-8)
  • Support Digital Diagnostic Monitoring interface
  • QSFP-DD MSA package with duplex LC connector
  • RoHs-10 compliant and lead-free
  • Compliant to QSFP-DD MSA standard
  • Single +3.3V power supply
  • Maximum power consumption 12W
  • All-metal housing for superior EMI performance
  • Case operation temperature: 0℃ to+ 70℃/ -40℃ to +85℃



Order information



Product Number

Data Rate(Gb/s)

Wavelength(nm)

Reach(km)

LD

Tx Power(dBm)

PD

Rx Sens(dBm)

Temperature(℃)

RQ-400G-FR4

400

1271-1331nm

2

CWDM EML

-3.3~3.5

PIN

<-5

0~70

RQ-400G-FR4-I

400

1271-1331nm

2

CWDM EML

-3.3~3.5

PIN

<-5

-40~85
