LC/SC/FC/ST光纤跳线

High dense space
Ceramic ferrules connector
Low insertion loss
High return loss
Excellent mechanical endurance
High credibility and stability

现在查询

类别

热门产品

产品详细信息

Optical Fiber Patch Cord

Features

High dense space
Ceramic ferrules connector
Low insertion loss
High return loss
Excellent mechanical endurance
High credibility and stability

Applications

Telecommunication
CATV, FTTH, LAN
Fiber sensor
Optical transmission system
Test equipment

Performance Specifications

Parameter	FC, SC, LC		ST, MU		MTRJ
	SM		MM	SM	MM	SM	MM
	UPC	APC	UPC	UPC	UPC	UPC	UPC
Operating Wavelength (nm)	1310/1550		850/1300	1310/1550	850/1300	1310/1550	850/1300
Diameter	0.9mm, 2.0mm, 3.0mm
Insertion Loss (dB)	≤ 0.3
Return Loss (dB)	≥ 55	≥ 60	≥ 35	≥ 50	≥ 35	≥ 50	≥ 35
Repeatability (dB)	≤ 0.1
Interchangeability (dB)	≤ 0.2
Plug Times (times)	≥ 1000
Tensil Strength (N)	≥ 100
Durability (dB)	≤ 0.2
Fiber	Corning SMF-28E
Operating Temperature (℃)	-40 ~ +75
Storage Temperature (℃)	-40 ~ +85
