MXN MEMS 光开关

Features

Proven MEMS durability and reliability
Compact Form Factor
TTL UART interface
Qualified to Telcordia GR-1073-CORE and RoHS

Applications

Optical path selection
AsAutomatic optical distribution rack

现在查询

类别

热门产品

产品详细信息

M x N MEMS Optical Switch OXC

M x N MEMS Optical switch is used in optical cross-connect, OXC application. It’s also called Matric Optical Switch. It allows channel selections between M input fibers and N output fibers.

FIBERWDM’s MEMS Modular Single-Mode OXC is based on industry proven, long-life, reliable MEMS 1xN optical switch components. Each MxN OXC consists of M 1xn OSW and N 1xm OSW.

Product Configurations

Note: M*N requires less than 1024.

Optical Specifications

PARAMETER		VALUE	UNIT	NOTE
Wavelength		1290~1330 1525~1568 1600-1650	nm	Or customer specify
Test Wavelength		1310/1550/1625 or 1650	nm
MxN		8x8/8x16/16x16/16x32		M*N≤1024
Insertion Loss	4x4	≤1.4 @S	dB	@CWL,23°C Without Connectors @S: 13 or 15 or 16 @D: 13&15 or 15&16 (if with connectors or support @D, IL increased by 0.4dB)
	4x8	≤1.6 @S
	8x8	≤1.8 @S
	8x16	≤1.9 @S
	12x12	≤2.0 @S
	16x16	≤2.0 @S
	16x32	≤2.3 @S
	24x24	≤2.5 @S
Return Loss		≥45	dB	Or customer specify
Repeatability		≤0.1	dB
Crosstalk		≥50	dB	Or customer specify
Polarization Dependence Loss		≤0.4	dB
Wavelength Dependence Loss		≤0.6	dB	@CWL±20nm, 23°C
Temperature Dependence Loss		≤0.8	dB
Switch Time		≤15 @16x16 ≤25 @24x24	ms	A set of configuration link Eg: M1-N12
Durability		≥1x10⁹	cycle
Maximum optical Power		≤500	mW

Electrical and Mechanical Specifications

PARAMETER	VALUE	UNIT	NOTE
Switch Mode	Non-latching
Control Voltage	12	V	Module
Dimension	150×150×20 @8x8 200x180x18 @16x16 200x180x18 @8x24 312x180x30 @24x24	mm	Module

Environmental conditions

PARAMETER	VALUE	UNIT	NOTE
Operation Temperature	-5~65	°C
Storage Temperature	-40~85	°C
Operation Humidity	5~95	%RH
Storage Humidity	5~95	%RH

Pigtail and connector type/length

PARAMETER	VALUE	UNIT	NOTE
Fiber Type	G657A2 or G657B3 250um bare fiber
Fiber Pigtail(All Ports)	250um fiber or 900um loose tube
Fiber Length(All Ports)	1.00±0.05	m	Or customer specify
Optical Connector(All port)	None		Or customer specify

MECHANICAL DRAWINGS

8x8 OXC MEMS Optical Swtich

16x16 OXC MEMS Optical Swtich

24x 24 OXC MEMS Optical Swtich
